BALL JOINTS(ROD ENDS)
|
Model No.
|
Dimensions(mm)
|
Load ratings kN
|
Weight≈kg
|
Inventory
|
| d |
d1 |
d2 |
L1min |
L2 |
L3max |
Lmax |
S1 |
C |
D |
r1smin |
a°≈ |
|
SQD5
|
5
|
M5
|
9
|
8
|
8
|
19
|
27.5
|
7
|
6
|
16
|
0.3
|
25
|
2
|
0.014
|
○
|
|
SQD6
|
6
|
M6
|
10
|
11
|
8.8
|
23.8
|
33.5
|
8
|
6.75
|
18
|
0.3
|
25
|
3.2
|
0.021
|
○
|
|
SQD8
|
8
|
M8
|
12
|
12
|
11.6
|
28.6
|
41
|
10
|
9
|
22
|
0.3
|
25
|
5.7
|
0.042
|
○
|
|
SQD10
|
10
|
M10×1.25
|
14
|
15
|
14.2
|
34.2
|
49
|
11
|
10.5
|
26
|
0.3
|
25
|
9.2
|
0.067
|
○
|
|
SQD10-1
|
10
|
M10×1.5
|
14
|
21
|
14.2
|
40.2
|
55
|
11
|
10.5
|
26
|
0.3
|
25
|
9.2
|
0.067
|
○
|
|
SQD12
|
12
|
M12×1.25
|
17
|
17
|
15.1
|
38.1
|
55.1
|
15
|
12
|
30
|
0.5
|
25
|
14
|
0.108
|
○
|
|
SQD12-1
|
12
|
M12×1.75
|
17
|
24
|
15.1
|
45.1
|
62.1
|
15
|
12
|
30
|
0.5
|
25
|
14
|
0.108
|
○
|
|
SQD14
|
14
|
M14×1.5
|
19
|
22
|
16.8
|
51.3
|
70.7
|
17
|
13.5
|
34
|
0.5
|
20
|
19
|
0.167
|
○
|
|
SQD14-1
|
14
|
M14×2
|
19
|
28
|
16.8
|
57.3
|
76.7
|
17
|
13.5
|
34
|
0.5
|
20
|
19
|
0.167
|
○
|
|
SQD16
|
16
|
M16×1.5
|
22
|
23
|
18
|
54.5
|
76.3
|
19
|
15
|
38
|
0.5
|
20
|
26
|
0.238
|
○
|
|
SQD16-1
|
16
|
M16×2
|
22
|
29
|
18
|
60.5
|
82.3
|
19
|
15
|
38
|
0.5
|
20
|
26
|
0.238
|
○
|
