ROD ENDS
|
Model No.
|
Dimensions(mm)
|
Load ratings kN
|
Radial clearance(mm)
|
Weight≈kg
|
Inventory
|
| d Tolerances |
B0-0.12 |
dk |
C1 |
d2 |
G2A |
h |
L1min |
a°≈ |
Load ratings kN/Static |
|
CM3*
|
4.826
|
7.92
|
11.10
|
5.94
|
15.68
|
10-32
|
31.75
|
19.05
|
10
|
5.355
|
0.01～0.03
|
0.014
|
√
|
|
CM3*
|
0.1900
|
0.312
|
0.437
|
0.234
|
0.625
|
10-32
|
1.250
|
0.750
|
10
|
5.355
|
0.01～0.03
|
0.014
|
√
|
|
CM4*
|
6.350
|
9.53
|
12.70
|
6.35
|
19.05
|
1/4-28
|
39.67
|
25.40
|
13.5
|
9.839
|
0.01～0.03
|
0.016
|
√
|
|
CM4*
|
0.2500
|
0.375
|
0.500
|
0.250
|
0.750
|
1/4-28
|
1.562
|
1.000
|
13.5
|
9.839
|
0.01～0.03
|
0.016
|
√
|
|
CM5*
|
7.938
|
11.10
|
15.88
|
7.92
|
22.23
|
5/16-24
|
47.63
|
31.75
|
11
|
15.910
|
0.01～0.03
|
0.032
|
√
|
|
CM5*
|
0.3125
|
0.437
|
0.625
|
0.312
|
0.875
|
5/16-24
|
1.875
|
1.250
|
11
|
15.910
|
0.01～0.03
|
0.032
|
√
|
|
CM6
|
9.525
|
12.70
|
18.26
|
9.12
|
25.40
|
3/8-24
|
49.23
|
31.75
|
11
|
22.542
|
0.015～0.06
|
0.050
|
√
|
|
CM6
|
0.3750
|
0.500
|
0.719
|
0.359
|
1.000
|
3/8-24
|
1.938
|
1.250
|
11
|
22.542
|
0.015～0.06
|
0.050
|
√
|
|
CM7
|
11.113
|
14.27
|
20.62
|
10.31
|
28.58
|
7/16-20
|
53.98
|
34.93
|
10.5
|
28.223
|
0.015～0.06
|
0.066
|
√
|
|
CM7
|
0.4375
|
0.562
|
0.812
|
0.406
|
1.125
|
7/16-20
|
2.125
|
1.375
|
10.5
|
28.223
|
0.015～0.06
|
0.066
|
√
|
|
CM8
|
12.7
|
15.88
|
23.60
|
11.50
|
33.32
|
1/2-20
|
61.93
|
38.10
|
10
|
37.087
|
0.015～0.06
|
0.109
|
√
|
|
CM8
|
0.5000
|
0.625
|
0.937
|
0.453
|
1.312
|
1/2-20
|
2.438
|
1.500
|
10
|
37.087
|
0.015～0.06
|
0.109
|
√
|
|
CM10
|
15.875
|
19.05
|
28.58
|
12.29
|
38.10
|
5/8-18
|
66.68
|
41.28
|
13
|
43.203
|
0.04～0.08
|
0.163
|
√
|
|
CM10
|
0.6250
|
0.750
|
1.125
|
0.484
|
1.500
|
5/8-18
|
2.625
|
1.625
|
13
|
43.203
|
0.04～0.08
|
0.163
|
√
|
|
CM12
|
19.05
|
22.23
|
33.32
|
15.06
|
44.45
|
3/4-16
|
73.03
|
44.45
|
12
|
63.193
|
0.04～0.08
|
0.259
|
√
|
|
CM12
|
0.7500
|
0.875
|
1.312
|
0.593
|
1.750
|
3/4-16
|
2.875
|
1.750
|
12
|
63.193
|
0.04～0.08
|
0.259
|
√
|
